Percentile 3x3

Variations

About This Filter

Author

• Author: fisholith
• Contact the author
• All filters by this author (2)

Description
===OverviewThis is a 3x3 (9 sample) "Percentile" filter with an adjustable radius. It provides the functionality of a Median filter (value 5), a Maximum filter (value 9), and a Minimum filter (value 1).For more info see:http://www.filterforge.com/forum/read.php?FID=10&TID=&MID=80553#message80553===Controls:The "Radius" value determines how far apart sample rows and columns are in the 3x3 sample array. Note that increasing the "Radius" value will shift the sample rows and columns farther apart, but will still only sample 9 input pixels for each output pixel. By default, distance is measured as a percentage of the image's total width, where a value of 100 yields a 100% sample separation distance. However, with the "Fine (max = 1%)" option is enabled, a "Radius" value of 100 yields a 1% sample separation distance. It is recommended that you have "Fine (max = 1%)" enabled, and use a small "Radius" value to achieve conventional median / minimum / maximum effects.

Keywords
median max maximum min minimum percentile simplify soften convolution blur defuse smooth despeckle

Filter Details

• Downloads: 1809
• Submitted: Jan 25, 2010
• Usage Rank: Low
• Comments (0)

Filter Controls

• Radius
• Fine (max = 1%)
• Value: 1mn, 5md, 9mx
